Decreasing level permeability set
Product Code: SL246-KIT
Categories:
Standard: CEN ISO / TS 17892-11
SL246-01 - Vertical and Fixed Pipe Panel
Suitable for falling head tests, contains 4 glass tubes. With holes of 21, 12, 5 and 3.5 mm diameter, it serves as a support for a water reservoir every 1 meter in length. Mounted on the wall.
Dimensions: 320 x 250 x 1380 (h) mm
Approximate weight: 10 kg
SL252 - Compression Permeameter Cell - 4" Diameter
Central body Ø 101.6 x 116.4 mm
Approximate weight: 7 kg
SL243 - Compression Permeameter Cell - 6" Diameter
Central body Ø 152.4 x 177.8 mm
Approximate weight: 13 kg
SL246-02 - Infiltration Tank
Used for SL246-01 permeameter, equipped with an overflow valve to maintain a constant level.
Dimensions: diameter 360 x 285 (h) mm
Weight: 6 kg
SL246-03 - Air Release Tank
Anodized aluminum base and attachments for wall mounting. Made of transparent Perspex. Has air jet inlet and outlet holes.
Capacity: 15 liters
Dimensions: 800 x 220 x 220 mm
Weight: 10 kg
