ROV Robot (Human-Carry)

The TD-400 EOD Robot is the only small and medium-sized EOD robot featuring a dual gripper design, super multi-perspective function, and integrated exploration, transfer, and disposal capabilities. As a compact EOD robot, the TD-400 has a small volume with a weight of only 37 kg; however, its operational capacity meets the standard of medium-sized EOD robots. The robot is a robust, lightweight, precise, versatile, reliable, and flexible robot in use.

Technical Specifications

• Dimensions: 830 x 600 x 460 mm
• Ground Clearance: 4.5 cm
• Towing Capacity: 30 kg
• Payload Capacity: 5 kg
• Stairs: Angle - 40°; Height - 20 cm
• Trench: 40 cm
• Speed: 3 km/h
• Weight: 37 kg

Arm Features

1. Degrees of freedom: 5 axes
2. Turret: ±100°
3. Shoulder: 180°
4. Elbow: 180°
5. Wrist: 300°
6. Gripper Rotation: 360° continuous rotation

Manipulator

1. Lifting Capacity: 4 kg
2. Vertical and Horizontal Reach: 100 cm

Camera and Power System

Camera: LED-lit rear and front cameras, tilt with manipulator arms, pan with ROV, rotate as needed.

• Battery: Lithium-ion battery / 2 units / 33.3V / 6Ah
• Backup Time: 2 Hours
• Operating Mode: Wired (200m) and Wireless (100m)
• Radio frequency: 2.5 GHz Spread Spectrum Technology

Command Control Unit

1. Battery: 1 unit
2. Battery backup with full payment load
3. Continuous operating time with full payment load
4. CCU for operating the robot
5. Multi-functional control, variable speed joystick
6. 10-inch LCD screen readable in daylight
7. Battery status indicator
8. Auxiliary video jack output
9. Audio output and MP3 audio input
10. IP66 Weather resistant

Gripper Attachment Kit

1. Camera Extension
2. Cutter
3. Clothing Cutter
4. Box Opener
5. Rubber Cutters
6. Bottle Piercer
7. Box Closer
8. Lens Puller
9. Mail Catcher

Standard Accessories

1 unit ROV; 1 unit Manual; 1 unit Toolbox; 1 unit Cable; 1 unit Gasket.
